Specification
Audio and Video |
||
| IP Camera Input | 2-ch(only IP up to 10ch), each channel up to 6MP | |
Display |
||
| Interface | 1x HDMI, 1x VGA | |
| Resolution | 1080P Lite/720P/D1 | |
| Decoding Capacity | Analog:8x 1080P Lite @15, 8x 720P @15 IP: 1 x 6MP@20, 2 x 1080P@30 |
|
Recording |
||
| Resolution | Main Stream: 1080P Lite Main stream: 720P |
|
| Record Rate | Main Stream: 1080P Lite@15fps Sub stream: D1@12fps Main stream: 720P@15fps Sub stream:D1@15fps |
|
| Bit Rate | Audio Sample Rate: 8KHz,16 bit per channel Audio Bit Rate: 64Kbps per channel |
|
Playback And Backup |
||
| Backup Mode | USB | |
Network |
||
| Interface | 1x RJ45, 2x USB2.0 | |
Storage |
||
| eSATA | Up to 6TB for each HDD | |
Auxiliary Interface |
||
| USB | 2x USB2.0 | |
Power |
||
| Power Supply | DC12V/2A | |
| Power Consumption | ≤ 10 W( without HDD ) | |
Construction |
||
| Dimensions | 190mm × 202mm × 42mm (7.5″ × 7.9″ × 1.6″) | |
| Gross Weight | ≤0.6 Kg ( 1.32lb ) | |
Warranty |
||
| Manufacturing Warranty | 1 Year | |
