Specification
Camera Feature |
||
| Image Sensor | 1/2.9″, 2.0 megapixel, CMOS sensor | |
| IR Distance | Warm Light, up to 30m (98ft) warm light distance | |
| Others | Minimum Illumination: Colour: 0.005 lux ( F1.6, AGC ON) Shutter: Auto/Manual, 1 ~ 1/100000s Material: Metal+Plastic |
|
Lens |
||
| Type | 2.8mm@F1.6 | |
| Angle of View | 101.1° x 55.0° x 111.0° (H x V x D) | |
| Others | Lens Mount: M12 IR Distance: Up to 30m (98ft) IR range IR Control: Auto/Manual Flip: Normal/ Vertical/ Horizontal/ 180°/ 90°Clockwise/ 90°Anti-clockwise Digital Noice Reduction: 2D/ 3D DNR |
|
Physical Specification |
||
| Dimension | Φ118 x 98mm (Ø4.6” x 3.9”) | |
| Weight | 0.29kg (0.53lb) | |
| Power | DC 12V±25%, PoE (IEEE 802.3af) Power consumption: Max 7.3W |
|
| Interface | Power Interface: Ø 5.5mm coaxial power plug Network Interface: 1 * RJ45 10M/100M Base-TX Ethernet |
|
| Others | Working Environment: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) Water & Dust Protection: IP67 Reset Button: N/A Surge Protection: 4KV Network Storage: ANR, NAS(NFS) Defog: Digital Defog |
|
Warranty |
||
| Warranty | 1 Year Warranty | |
