Specification
Basic Information |
||
| Processor | CPU Model: Intel Xeon D-1527 CPU Quantity: 1 CPU Architecture: 64-bit CPU Frequency: 4-core 2.2 (base) / 2.7 (turbo) GHz |
|
| Memory | System Memory: 8 GB DDR4 ECC UDIMM Memory Module Pre-installed: 8 GB (8 GB x 1) Total Memory Slots: 4 Maximum Memory Capacity: 64 GB (16 GB x 4) |
|
| Hard Disk | 3.5″ SATA HDD: HAT5300 2.5″ SATA SSD: SAT5210 |
|
| Network | 25GbE Network Interface Card: E25G21-F2 10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1 |
|
| Mount | 4-post 19″ rack (Synology Rail Kit – RKM114/RKS-02) | |
Additional Features |
||
| Power Supply and Cable | 150 W AC Input Power Voltage: 100V to 240V AC Power Frequency: 50/60 Hz, Single Phase Power Consumption: 68.68 W (Access) 34.78 W (HDD Hibernation) |
|
| Drive Bays | 2 (NVMe & SATA) | |
| Form Factor | 1U | |
| Others | Maximum Drive Bays with Expansion Unit: 16 (RX1217/RX1217RP x 1) RJ-45 1GbE LAN Port: 4 (with Link Aggregation / Failover support) USB 3.2 Gen 1 Port*: 2 Expansion Port: 1 PCIe Expansion: 1 x Gen3 x8 slot (x8 link) Internal Drives: Btrfs, EXT4 External Drives: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT Size (Height x Width x Depth): 44 mm x 480 mm x 518.6 mm Weight: 8.16 kg System Fan: 40 mm x 40 mm x 2 pcs Fan Speed Mode: Full-Speed Mode, Cool Mode, Quiet Mode Operating Temperature: 5°C to 35°C (40°F to 95°F) Storage Temperature: -20°C to 60°C (-5°F to 140°F) Relative Humidity: 5% to 95% RH |
|
Manufacture Warranty |
||
| Warranty | 5 Year | |
