Specification
General Information |
||
| Image Sensor | 1/2.8″ Progressive Scan CMOS | |
| Effective Pixels | 3MP | |
| Max. Resolution | 2304 × 1296 | |
| Frame Rate | Max:30fps; Self-Adaptive during network transmission | |
| Lens | 4mm@ F1.6, | |
| Pan & Tilt | Pan: 350°, Tilt: 80° | |
| IR Distance | 30m / 98ft | |
| Field of View | 4mm@ F1.6, viewing angle: 46° (Vertical), 86° (Horizontal), 102° (Diagonal) | |
| Min. Illumination | 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories) | |
| Video Compression | H.265 / H.264 | |
| Audio Input / Output | Two-way Talk Supported | |
| DNR | 3D DNR | |
| WDR | Digital WDR | |
| Smart Alarm | Human Motion Detection,Vehicle Detection | |
| Storage Type | Supports microSD Card (Up to 512 GB) Supports EZVIZ CloudPlay storage (Subscription required) |
|
| Certifications | CE / WEEE / RoHS / REACH | |
Network & Connectivity |
||
| Wired Network | RJ45 × 1 (10M / 100M Adaptive Ethernet Port) | |
| Others | Weatherproof Design | |
Power |
||
| Power Supply | DC 12V/1A | |
Physical Specification |
||
| Dimension | Product Dimensions: 100 × 136 × 140mm (3.94 × 5.35 × 5.51 inch) Packaging Dimensions: 140 × 140 × 192mm (5.51 × 5.51 × 7.56 inch) |
|
| Weight | Net Weight: 513.8 g (18.12 oz) With Package: 796.7 g (28.1 oz) For EU Standard Version |
|
| Operating Temperature | -30°C to 50°C ( -22 °F to 122 °F ) Humidity 95% or less (non-condensing) | |
