Specification
General Information |
||
| Image Sensor | 1/2.7″ Progressive Scan CMOS | |
| Effective Pixels | 5MP | |
| Max. Resolution | 2880*1620 | |
| Frame Rate | Max:30fps; Self-Adaptive during network transmission | |
| Lens | 4mm@ F1.6, M12 Mount | |
| Pan & Tilt | Pan: 350°, Tilt: 80° | |
| IR Distance | 30m / 98ft | |
| Field of View | Viewing angle: 48° (Vertical), 91° (Horizontal), 108° (Diagonal) 6mm@ F1.6, viewing angle: 30° (Vertical), 56° (Horizontal), 66° (Diagonal) | |
| Min. Illumination | 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR | |
| Video Compression | H.265 / H.264 | |
| Audio Input / Output | Two Way Audio | |
| DNR | 3D DNR | |
| WDR | Digital WDR | |
| Smart Alarm | AI-Powered Human / Vehicle Shape Detection | |
| Button | Reset Button | |
| Storage Type | Supports microSD Card (Up to 512 GB) Supports EZVIZ CloudPlay storage (Subscription required) |
|
| Certifications | CE / UL / RoHS / WEEE / REACH | |
Network & Connectivity |
||
| Wireless Network | IEEE802.11b, 802.11g, 802.11n 2.4 GHz ~ 2.4835 GHz |
|
| Wired Network | RJ45 × 1 (10M / 100M Adaptive Ethernet Port) | |
Power |
||
| Power Supply | DC 12V/1A | |
Physical Specification |
||
| Dimension | 100 × 136 × 140mm (3.94 × 5.35 × 5.51 inch) | |
| Weight | Net Weight: 539.7g; With Package: 823.6g For EU Standard Version | |
| Operating Temperature | -30°C to 50°C ( -22 °F to 122 °F ) Humidity 95% or less (non-condensing) | |
| Others | Weatherproof Design | |
Warranty Information |
||
| Warranty | 01 Year Warranty | |
